Air Preparation Equipment
As part of our pneumatic component supply, MacScott Bond hold a stock of Filters, Regulators, and Lubricators. These kits offer different treatments for compressed air to remove contamination such as water, oil, or debris from the air lines before reaching your pneumatic components and causing damage. The lubricators also add appropriate lubrication, while regulators control the pressure/flow, ensuring that your pneumatic components are receiving the optimal, clean compressed air required for your application. With such a wide range of options, if you need help sizing the right clean air system to meet your flow demands, please get in touch.
Maximum 14 bar | 270 scfm (127 l/s)
Aluminium Bowl | Wick Feed
17 bar (Outlet) | 800 scfm (377 l/s)
Precision | Self-Relieving
17 bar (Outlet) | 400 scfm (188 l/s)
Remote Pilot | Self-Relieving | High-Relief
7 bar (Outlet) | 800 scfm (377 l/s)
Standard | Self-Relieving | Reverse Flow
7 bar (Outlet) | 800 scfm (377 l/s)
Standard | Self-Relieving
Up to 10 bar | 270 scfm (127 l/s)
Polycarbonate Bowl | Tamper Resistant
Up to 14 bar | 270 scfm (127 l/s)
Zinc Bowl | Tamper Resistant
Maximum 10 bar | 500 scfm (235 l/s)
Polycarbonate Bowl | Sight/Wick Feed
Maximum 14 bar | 500 scfm (235 l/s)
Extended Aluminium Bowl | Sight Feed
Maximum 14 bar | 500 scfm (235 l/s)
Aluminium Bowl | Sight Feed
Maximum 14 bar | 500 scfm (235 l/s)
Aluminium Bowl | Sight/Wick Feed
14 bar (Outlet) | 4,000 scfm (1,887 l/s)
Remote Pilot | Self-Relieving | In-Line | High Flow
14 bar (Outlet) | 700 scfm (330 l/s)
Remote Pilot | Self-Relieving | In-Line | High Relief
14 bar (Outlet) | 740 scfm (349 l/s)
Remote Pilot | Self-Relieving | In-Line
14 bar (Outlet) | 450 scfm (212 l/s)
Relief Valve | Self Relieving | High Flow
Maximum 14 bar | 110 scfm (52 l/s)
Metal Bowls | Float Drain | Diaphragm Regulator | Sight-Feed | BSP
0 - 10 bar | 125 scfm (59l/s)
Coalescing | Polycarbonate Bowl | Manual Drain
0 - 10 bar | 125 scfm (59l/s)
Coalescing | Polycarbonate Bowl
2 - 10 bar | 125 scfm (59l/s)
Coalescing | Polycarbonate Bowl | Float Drain
0 - 17 bar | 125 scfm (59l/s)
Coalescing | Metal Bowl | Manual Drain
0 - 17 bar | 125 scfm (59l/s)
Coalescing | Metal Bowl
2 - 14 bar | 125 scfm (59l/s)
Coalescing | Metal Bowl | Float Drain
0 - 17 bar | 125 scfm (59l/s)
Coalescing | Extended Metal Bowl | Manual Drain
0 - 17 bar | 125 scfm (59l/s)
Coalescing | Extended Metal Bowl
2 - 14 bar | 125 scfm (59l/s)
Coalescing | Extended Metal Bowl | Float Drain
0 - 17 bar | 92 scfm (43 l/s)
Standard | Metal Bowl | Manual Drain
2 - 14 bar | 92 scfm (43 l/s)
Standard | Metal Bowl
2 - 14 bar | 92 scfm (43 l/s)
Standard | Metal Bowl | Float Drain
2 - 10 bar | 92 scfm (43 l/s)
Standard | Polycarbonate Bowl
2 - 10 bar | 92 scfm (43 l/s)
Standard | Polycarbonate Bowl | Float Drain
0 - 10 bar | 92 scfm (43 l/s)
Standard | Polycarbonate Bowl | Manual Drain
14 bar (Outlet) | 120 scfm (56 l/s)
Standard | Self-Relieving | Locking Knob | Standard Flow | NPTF
14 bar (Outlet) | 120 scfm (56 l/s)
Standard | Self-Relieving | Locking Knob | Standard Flow | BSP
14 bar (Outlet) | 120 scfm (56 l/s)
Standard | Self-Relieving | Locking Knob | Reverse Flow | NPTF
14 bar (Outlet) | 120 scfm (56 l/s)
Standard | Self-Relieving | Locking Knob | Reverse Flow | BSP
14 bar (Outlet) | 120 scfm (56 l/s)
Standard | Self-Relieving | T-Handle | Standard Flow | NPTF
14 bar (Outlet) | 120 scfm (56 l/s)
Standard | Self-Relieving | T-Handle | Standard Flow | BSP
14 bar (Outlet) | 120 scfm (56 l/s)
Standard | Self-Relieving | T-Handle | Reverse Flow | NPTF
14 bar (Outlet) | 120 scfm (56 l/s)
Standard | Self-Relieving | T-Handle | Reverse Flow | BSP
14 bar (Outlet) | 120 scfm (56 l/s)
Standard | Self-Relieving | Adjusting Knob | Standard Flow | NPTF
14 bar (Outlet) | 120 scfm (56 l/s)
Standard | Self-Relieving | Adjusting Knob | Standard Flow | BSP
14 bar (Outlet) | 120 scfm (56 l/s)
Standard | Self-Relieving | Adjusting Knob | Reverse Flow | NPTF
14 bar (Outlet) | 120 scfm (56 l/s)
Standard | Self-Relieving | Adjusting Knob | Reverse Flow | BSP
Maximum 10 bar | 110 scfm (52 l/s)
Polycarbonate Bowls | Manual Drain | Diaphragm Regulator | Sight-Feed | NPTF
Maximum 14 bar | 110 scfm (52 l/s)
Metal Bowl (Extended) | Manual Drain | Diaphragm Regulator | Sight-Feed | NPTF
Maximum 14 bar | 110 scfm (52 l/s)
Metal Bowls | Manual Drain | Diaphragm Regulator | Sight-Feed | NPTF
Maximum 10 bar | 110 scfm (52 l/s)
Polycarbonate Bowls | Manual Drain | Diaphragm Regulator | Sight-Feed | BSP
Maximum 14 bar | 110 scfm (52 l/s)
Metal Bowl (Extended) | Manual Drain | Diaphragm Regulator | Sight-Feed | BSP
Recently viewed
Still not sure? Reach out for expert help on products
If you have any queries, need a quote for one of our products or want some technical advice from one of our engineers, please get in touch and a member of MacScott Bond will assist.
A History in Pneumatics
MacScott Bond has been supplying air motors in the UK since the early days of our company in the 1970s. Through our experience with air motors, we have seen that the best way of improving your pneumatic components’ life and reducing maintenance costs overall is to prepare the air flowing through them. MacScott Bond holds a stock of Ross Controls’ Filter, Regulator, Lubricators, which have been sized to match requirements for the Globe air motors in our range. If you have an air motor application, remember to ask MacScott Bond about the rest of the pneumatic circuit and we will be able to supply an appropriate FRL assembly.
