Robust High Energy Shock Absorption
ACE industrial shock absorbers are designed to evenly decelerate moving loads over the full stroke, resulting in the lowest braking force and shortest braking time. The Magnum series sets the standard for damping technology at this size, featuring innovations such as diaphragm accumulators, seals, and tube-shaped inner pressure chambers that significantly extend service life and effective load range. A wide range of matching accessories is available, eliminating the need for costly and time-consuming internal production of assembly parts.
Stroke: 23.2mm | Energy Capacity: 170 Nm/Cycle
Adjustable | Effective Weight 9 - 1,700kg
Stroke: 48.6mm | Energy Capacity: 340 Nm/Cycle
Adjustable | Effective Weight 13 - 2,500kg
Stroke: 23.1mm | Energy Capacity: 425 Nm/Cycle
Adjustable | Effective Weight 40 - 10,000kg
Stroke: 48.5mm | Energy Capacity: 850 Nm/Cycle
Adjustable | Effective Weight 70 - 14,500kg
Stroke: 73.9mm | Energy Capacity: 1,300 Nm/Cycle
Adjustable | Effective Weight 70 - 15,000kg
Stroke: 99.4mm | Energy Capacity: 4,520 Nm/Cycle
Adjustable | Effective Weight 270 - 52,000kg
Stroke: 150mm | Energy Capacity: 6,780 Nm/Cycle
Adjustable | Effective Weight 330 - 80,000kg
Stroke: 48.6mm | Energy Capacity: 2,275 Nm/Cycle
Adjustable | Effective Weight 220 - 50,000kg
Stroke: 23.2mm | Energy Capacity: 170 Nm/Cycle
Self-Compensating | Effective Weight 3 - 1,420kg
Stroke: 23.2mm | Energy Capacity: 170 Nm/Cycle
Self-Compensating, High Temperatures | Effective Weight 3 - 1,420kg
Stroke: 23.2mm | Energy Capacity: 170 Nm/Cycle
Self-Compensating, Extreme Low Temperatures | Effective Weight 3 - 1,420kg
Stroke: 23.2mm | Energy Capacity: 170 Nm/Cycle
Self-Compensating, Stainless Steel | Effective Weight 3 - 1,420kg
Stroke: 48.6mm | Energy Capacity: 330 Nm/Cycle
Self-Compensating | Effective Weight 5 - 2,830kg
Stroke: 48.6mm | Energy Capacity: 330 Nm/Cycle
Self-Compensating, High Temperatures | Effective Weight 5 - 2,830kg
Stroke: 48.6mm | Energy Capacity: 330 Nm/Cycle
Self-Compensating, Extreme Low Temperatures | Effective Weight 5 - 2,830kg
Stroke: 48.6mm | Energy Capacity: 330 Nm/Cycle
Self-Compensating, Stainless Steel | Effective Weight 5 - 2,830kg
Stroke: 23.1mm | Energy Capacity: 370 Nm/Cycle
Self-Compensating | Effective Weight 7 - 3,540kg
Stroke: 23.1mm | Energy Capacity: 370 Nm/Cycle
Self-Compensating, High Temperatures | Effective Weight 7 - 3,540kg
Stroke: 23.1mm | Energy Capacity: 370 Nm/Cycle
Self-Compensating, Extreme Low Temperatures | Effective Weight 7 - 3,540kg
Stroke: 23.1mm | Energy Capacity: 370 Nm/Cycle
Self-Compensating, Stainless Steel | Effective Weight 7 - 3,540kg
Stroke: 48.5mm | Energy Capacity: 740 Nm/Cycle
Self-Compensating | Effective Weight 13 -7,100kg
Stroke: 48.5mm | Energy Capacity: 740 Nm/Cycle
Self-Compensating, High Temperatures | Effective Weight 13 - 7,100kg
Stroke: 48.5mm | Energy Capacity: 740 Nm/Cycle
Self-Compensating, Extreme Low Temperatures | Effective Weight 13 - 7,100kg
Stroke: 48.5mm | Energy Capacity: 740 Nm/Cycle
Self-Compensating, Stainless Steel | Effective Weight 13 - 7,100kg
Stroke: 73.9mm | Energy Capacity: 1,130 Nm/Cycle
Self-Compensating | Effective Weight 20 - 10,600kg
Stroke: 73.9mm | Energy Capacity: 1,130 Nm/Cycle
Self-Compensating, Extreme Low Temperatures | Effective Weight 20 - 10,600kg
Stroke: 73.9mm | Energy Capacity: 1,130 Nm/Cycle
Self-Compensating, Stainless Steel | Effective Weight 20 - 10,600kg
Stroke: 99.4mm | Energy Capacity: 3,730 Nm/Cycle
Self-Compensating | Effective Weight 70 - 42,500kg
Stroke: 99.4mm | Energy Capacity: 3,730 Nm/Cycle
Self-Compensating, High Temperatures | Effective Weight 70 - 12,600kg
Stroke: 99.4mm | Energy Capacity: 3,730 Nm/Cycle
Self-Compensating, Extreme Low Temperatures | Effective Weight 70 - 42,500kg
Stroke: 99.4mm | Energy Capacity: 3,730 Nm/Cycle
Self-Compensating, Stainless Steel | Effective Weight 70 - 42,500kg
Stroke: 150mm | Energy Capacity: 5,650 Nm/Cycle
Self-Compensating | Effective Weight 100 - 63,700kg
Stroke: 150mm | Energy Capacity: 5,650 Nm/Cycle
Self-Compensating, Extreme Low Temperatures | Effective Weight 100 - 63,700kg
Stroke: 150mm | Energy Capacity: 5,650 Nm/Cycle
Self-Compensating, Stainless Steel | Effective Weight 100 - 63,700kg
Stroke: 48.6mm | Energy Capacity: 1,870 Nm/Cycle
Self-Compensating | Effective Weight 35 - 21,200kg
Stroke: 48.6mm | Energy Capacity: 1,870 Nm/Cycle
Self-Compensating, High Temperatures | Effective Weight 35 - 21,200kg
Stroke: 48.6mm | Energy Capacity: 1,870 Nm/Cycle
Self-Compensating, Extreme Low Temperatures | Effective Weight 35 - 21,200kg
Stroke: 48.6mm | Energy Capacity: 1,870 Nm/Cycle
Self-Compensating, Stainless Steel | Effective Weight 35 - 21,200kg
Stroke: 23.2mm | Energy Capacity: 170 Nm/Cycle
Adjustable | Effective Weight 300 - 50,000kg
Stroke: 48.6mm | Energy Capacity: 340 Nm/Cycle
Adjustable | Effective Weight 500 - 80,000kg
Stroke: 23.1mm | Energy Capacity: 425 Nm/Cycle
Adjustable | Effective Weight 3,000 - 110,000kg
Stroke: 48.5mm | Energy Capacity: 850 Nm/Cycle
Adjustable | Effective Weight 5,000 - 180,000kg
Stroke: 23.2mm | Energy Capacity: 1,135 Nm/Cycle
Adjustable | Effective Weight 7,000 - 300,000kg
Stroke: 48.6mm | Energy Capacity: 2,275 Nm/Cycle
Adjustable | Effective Weight 11,000 - 500,000kg
Stroke: 23.2mm | Energy Capacity: 155 Nm/Cycle
Self-Compensating, Soft-Contact
Stroke: 48.6mm | Energy Capacity: 310 Nm/Cycle
Self-Compensating, Soft-Contact
Stroke: 23.1mm | Energy Capacity: 340 Nm/Cycle
Self-Compensating, Soft-Contact
Stroke: 48.5mm | Energy Capacity: 680 Nm/Cycle
Self-Compensating, Soft-Contact
