Comprehensive Solutions for Effective Shock Absorption
Shock absorbers are critical components for ensuring smooth and safe operation of machinery and equipment, preventing damage, and enhancing overall performance. The key feature of ACE Controls shock absorbers is their versatility. They are available in various sizes, configurations, and damping characteristics to suit diverse requirements. Whether it's a high-speed production line or a heavy-duty manufacturing process, ACE shock absorbers can be tailored to meet specific needs. To ensure optimal performance and safety, ACE Controls offers an advanced calculation program. This tool assists in the accurate selection and dimensioning of shock absorbers by considering parameters such as moving mass, impact velocity, propelling force or power, number of shock absorbers in parallel, and stroke cycles per hour. MacScott Bond is committed to helping our customers select the right shock absorber for specific applications. Our team can help ensure the chosen solution meets all operational requirements and enhances overall machinery performance.
Stroke: 12mm | Energy Capacity: 41 Nm/Cycle
Self-Compensating, Rolling Diaphragm Technology
Stroke: 12.5mm | Energy Capacity: 41 Nm/Cycle
Self-Compensating, Rolling Diaphragm, Stainless Steel
Stroke: 6mm | Energy Capacity: 2.8 Nm/Cycle
Self-Compensating | Effective Weight 0.7 - 13.6kg
Stroke: 8mm | Energy Capacity: 3.5 Nm/Cycle
Self-Compensating | Effective Weight 0.4 - 15kg
Stroke: 23.2mm | Energy Capacity: 170 Nm/Cycle
Self-Compensating | Effective Weight 3 - 1,420kg
Stroke: 23.2mm | Energy Capacity: 170 Nm/Cycle
Self-Compensating, High Temperatures | Effective Weight 3 - 1,420kg
Stroke: 23.2mm | Energy Capacity: 170 Nm/Cycle
Self-Compensating, Extreme Low Temperatures | Effective Weight 3 - 1,420kg
Stroke: 23.2mm | Energy Capacity: 170 Nm/Cycle
Self-Compensating, Stainless Steel | Effective Weight 3 - 1,420kg
Stroke: 48.6mm | Energy Capacity: 330 Nm/Cycle
Self-Compensating | Effective Weight 5 - 2,830kg
Stroke: 48.6mm | Energy Capacity: 330 Nm/Cycle
Self-Compensating, High Temperatures | Effective Weight 5 - 2,830kg
Stroke: 48.6mm | Energy Capacity: 330 Nm/Cycle
Self-Compensating, Extreme Low Temperatures | Effective Weight 5 - 2,830kg
Stroke: 48.6mm | Energy Capacity: 330 Nm/Cycle
Self-Compensating, Stainless Steel | Effective Weight 5 - 2,830kg
Stroke: 23.1mm | Energy Capacity: 370 Nm/Cycle
Self-Compensating | Effective Weight 7 - 3,540kg
Stroke: 23.1mm | Energy Capacity: 370 Nm/Cycle
Self-Compensating, High Temperatures | Effective Weight 7 - 3,540kg
Stroke: 23.1mm | Energy Capacity: 370 Nm/Cycle
Self-Compensating, Extreme Low Temperatures | Effective Weight 7 - 3,540kg
Stroke: 23.1mm | Energy Capacity: 370 Nm/Cycle
Self-Compensating, Stainless Steel | Effective Weight 7 - 3,540kg
Stroke: 48.5mm | Energy Capacity: 740 Nm/Cycle
Self-Compensating | Effective Weight 13 -7,100kg
Stroke: 48.5mm | Energy Capacity: 740 Nm/Cycle
Self-Compensating, High Temperatures | Effective Weight 13 - 7,100kg
Stroke: 48.5mm | Energy Capacity: 740 Nm/Cycle
Self-Compensating, Extreme Low Temperatures | Effective Weight 13 - 7,100kg
Stroke: 48.5mm | Energy Capacity: 740 Nm/Cycle
Self-Compensating, Stainless Steel | Effective Weight 13 - 7,100kg
Stroke: 73.9mm | Energy Capacity: 1,130 Nm/Cycle
Self-Compensating | Effective Weight 20 - 10,600kg
Stroke: 73.9mm | Energy Capacity: 1,130 Nm/Cycle
Self-Compensating, Extreme Low Temperatures | Effective Weight 20 - 10,600kg
Stroke: 73.9mm | Energy Capacity: 1,130 Nm/Cycle
Self-Compensating, Stainless Steel | Effective Weight 20 - 10,600kg
Stroke: 4mm | Energy Capacity: 0.68 Nm/Cycle
Self-Compensating | Effective Weight 0.5 - 18.7kg
Stroke: 25mm | Energy Capacity: 136 Nm/Cycle
Self-Compensating, Rolling Diaphragm Technology
Stroke: 25.4mm | Energy Capacity: 136 Nm/Cycle
Self-Compensating, Rolling Diaphragm, Stainless Steel
Stroke: 99.4mm | Energy Capacity: 3,730 Nm/Cycle
Self-Compensating | Effective Weight 70 - 42,500kg
Stroke: 99.4mm | Energy Capacity: 3,730 Nm/Cycle
Self-Compensating, High Temperatures | Effective Weight 70 - 12,600kg
Stroke: 99.4mm | Energy Capacity: 3,730 Nm/Cycle
Self-Compensating, Extreme Low Temperatures | Effective Weight 70 - 42,500kg
Stroke: 99.4mm | Energy Capacity: 3,730 Nm/Cycle
Self-Compensating, Stainless Steel | Effective Weight 70 - 42,500kg
Stroke: 150mm | Energy Capacity: 5,650 Nm/Cycle
Self-Compensating | Effective Weight 100 - 63,700kg
Stroke: 150mm | Energy Capacity: 5,650 Nm/Cycle
Self-Compensating, Extreme Low Temperatures | Effective Weight 100 - 63,700kg
Stroke: 150mm | Energy Capacity: 5,650 Nm/Cycle
Self-Compensating, Stainless Steel | Effective Weight 100 - 63,700kg
Stroke: 48.6mm | Energy Capacity: 1,870 Nm/Cycle
Self-Compensating | Effective Weight 35 - 21,200kg
Stroke: 48.6mm | Energy Capacity: 1,870 Nm/Cycle
Self-Compensating, High Temperatures | Effective Weight 35 - 21,200kg
Stroke: 48.6mm | Energy Capacity: 1,870 Nm/Cycle
Self-Compensating, Extreme Low Temperatures | Effective Weight 35 - 21,200kg
Stroke: 48.6mm | Energy Capacity: 1,870 Nm/Cycle
Self-Compensating, Stainless Steel | Effective Weight 35 - 21,200kg
Stroke: 10mm | Energy Capacity: 9 Nm/Cycle
Self-Compensating | Effective Weight 0.3 - 72kg
Stroke: 5mm | Energy Capacity: 1 Nm/Cycle
Self-Compensating | Effective Weight 0.6 - 4.1kg
Stroke: 23.2mm | Energy Capacity: 170 Nm/Cycle
Adjustable | Effective Weight 300 - 50,000kg
Stroke: 48.6mm | Energy Capacity: 340 Nm/Cycle
Adjustable | Effective Weight 500 - 80,000kg
Stroke: 23.1mm | Energy Capacity: 425 Nm/Cycle
Adjustable | Effective Weight 3,000 - 110,000kg
Stroke: 48.5mm | Energy Capacity: 850 Nm/Cycle
Adjustable | Effective Weight 5,000 - 180,000kg
Stroke: 23.2mm | Energy Capacity: 1,135 Nm/Cycle
Adjustable | Effective Weight 7,000 - 300,000kg
Stroke: 48.6mm | Energy Capacity: 2,275 Nm/Cycle
Adjustable | Effective Weight 11,000 - 500,000kg
Stroke: 12.5mm | Energy Capacity: 20 Nm/Cycle
Self-Compensating, Rolling Diaphragm Technology, TPU Bellow
Stroke: 12.5mm | Energy Capacity: 20 Nm/Cycle
Self-Compensating, Rolling Diaphragm Technology, TPU Bellow, Stainless Steel
Stroke: 12.5mm | Energy Capacity: 41 Nm/Cycle
Self-Compensating, Rolling Diaphragm Technology, TPU Bellow
